Ortofon MC Quintet Red

Each Ortofon HIFI product from the official distribution for the Czech Republic is provided with a certification card, which is an integral part of the 2-year or 3-year warranty and a sticker. Use the central database of serial numbers and register your Ortofon product immediately after purchase.the appropriate serial nu...

En savoir plus ID : 158091 EAN: 5705796271102

Garantie du meilleur prix

Si vous trouvez ce produit moins cher ailleurs, nous vous remboursons la différence !
En savoir plus

Statut

Nouveau

Disponibilité

En stock Dernière pièce

Prix

295,99 € Livraison gratuite

Disponibilité

En stock Dernière pièce

- Each Ortofon HIFI product from the official distribution for the Czech Republic is provided with a certification card, which is an integral part of the 2-year or 3-year warranty and a sticker.
- Use the central database of serial numbers and register your Ortofon product immediately after purchase.the appropriate serial number, which is indicated on the enclosed card or on the label of the box.
- Registration applies only to the HIFi segment
- Warranty period: Ortofon HIFi - 2 years

-A 3 year warranty period based on registration of the product purchased from an authorised Ortofon dealer - Made in Denmark.

- REGISTRATION OF THE SERIAL NUMBER OF THE PRODUCT PURCHASED:

Output voltage at 1000 Hz, 5cm/s: 0.5 mV

Material: ABS / Aluminium

Channel balance at 1 kHz	< 1.5 dB
Channel separation at 1 kHz	> 21 dB
Channel separation at 15 kHz	> 14 dB

Frequency range at - 3 dB: 20-25,000 Hz

Seating at 315Hz: 65um

Tip radius: r/R 8/18 µm

Clamping force range: 2.1-2.5 g (21-25 mN)

Internal impedance, DC resistance: 7 Ohm

Recommended load resistance: > 20 Ohm

Professional installation and adjustment of the product by a specialist organisationis a condition for the application of the warranty.

Qualités

Pression recommandée

2,3 g

Gamme de fréquences

20 - 25 000 Hz

Poids

9 g

Astuce

Elliptique

Impédance

7 Ω

Malléabilité

15 um/mN

Type

Tension de sortie

0,5 mV

Angle de vue

20 °
